TV Ceiling Mount Bracket NBT560-15

TV Size 32″ – 57″
Max Load 68 kg
VESA 600*400mm
Tilt Angle +15°/-5°
Swivel +30°/-30°
Lift 28.5″ – 59.3″

Categories: ,

Integrated Cable Management System
An integrated cable management system hides all cabling within the extension column covers and through decorative ceiling cover.

Column Extension
Drop down column extension from ceiling by selecting different screw holes position for requested height. Each screw position designed for 2″ increments.

Drop Down Length
Full range of extension from 28.5″ to 59.3″

Screen Leveling Adjustment
To set parallelism of your screen after installation, simply release 2 security nuts behind the tilt mechanism and tighten once parallel of screen has set.

Simple Tilt Angles Adjustment
To tilt screen, simply release the knob located at the lower bottom of the column, by turning the knob clockwise or anti-clockwise to gain your desired tilt angle.

Horizontal Roll Angles
To roll left right horizontal screen angle, simply release the vertical knob on column, and turn screen according to your desired angle to the maximum of ±20°.
